    K68i 7 Channels Protection Relay Testing External GPS With TFT LCD Display

    Ask Lasest Price
    Brand Name : KINGSINE
    Model Number : K68i
    Certification : CE/ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 100 sets /month
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    K68i 7 Channels Protection Relay Testing External GPS With TFT LCD Display


    7 Channels K68i Protection Relay Testing with TFT LCD Display


    Description of K68i Protection Relay Test Set

    7 Channels (4x300V & 3x35A) outputs, Each output channels are independent and simultaneous control of magnitude, Phase angle and frequency values, able to inject DC, AC sine wave and up to 20x harmonics.

    Variable battery simulator, DC 0-300V, 120Watts max.

    Quick relay testing facility in Manual mode.

    3x35A & 4x300V independent high burden and accuracy output channels
    Lightweight, <20.5Kg
    Inbuilt 6.4” True color TFT LCD display, keyboard and rotary encoder, fully control without laptop
    Advance software testing modules for optional
    3-Years guarantee of free repair and life-long maintenance
    Free software upgrade



    Feature Of K68i Protection Relay Test Set

    Basic functions:

    DC test

    AC test

    Distance relay test

    Harmonic test

    Frequency test

    8 pairs binary inputs

    4 pairs binary outputs



    Type of relays can be tested:

    Items

    ANSI® No.

    Distance protection relay

    21

    Synchronising or synchronism-check relays

    25

    Undervoltage relays

    27

    Directional Power relays

    32

    Undercurrent or underpower relays

    37

    Negative sequence overcurrent relays

    46

    Overcurrent/ground fault relays

    50

    Inverse time overcurrent/ground fault relays

    51

    Power factor relays

    55

    Overvoltage relays

    59

    Voltage or current balance relays

    60

    Directional overcurrent relays

    67

    Directional ground fault relays

    67N

    DC overcurrent relays

    76

    Phase-angle measuring or out-of-step protection relays

    78

    Automatic reclosing devices

    79

    Frequency relays

    81

    Motor overload protection relays

    86

    Differential protection relays

    87

    Directional voltage relays

    91

    Voltage and power directional relays

    92


    (KINGSINE PRODUCTS EXHIBITION IN US)


    Specification Of K68i Protection Relay Test Set


    Aux. DC Voltage Source (Battery simulator)

    Range

    0~300V @ 120W max

    Accuracy

    0.5%Rg Guar.

    Binary Input

    Quantity

    8pairs

    Type

    wet/dry, up to 300Vdc max input

    Time resolution

    100us

    Sampling Rate

    10KHz

    Debounce time

    0~25ms (Software Controlled)

    Time range

    999.999s

    Time errors

    ±1ms @ ≤1s, ±0.1% @ >1s

    Galvanic isolation

    Isolated as 1,2,3,4-8 pairs

    Binary Output (Relay Type)

    Quantity

    4pairs

    Type

    Potential free relay contacts, software controlled

    Break Capacity AC

    Vmax: 400Vac / Imax:4A / Pmax:1000VA

    Break Capacity DC

    Vmax: 300Vdc / Imax:4A / Pmax:300W


    Advantage Of K68i Protection Relay Test Set

    Advance software functions (optional for selections):

    ● Differential test

    ● State sequence test

    ● Time characteristic test

    ● Advance distance test

    ● Synchronizer test

    ● Fault recurrence (fault play back)


    Inquiry us for more details.


    F&A

    Q: 1. What's your acceptable payment term?
    A: T/T and L/C at sight are our normal acceptable payment terms.


    Q: 2.How long is the warranty period?

    A:We provide 3-years guarantee of free repair and life-long maintenance.


    Q: 3.Why do we offer a three-year warranty?

    A:First of all,The quality goal of KINGSINE company is that no quality failure occurs within five years of customer use.

    The second,KINGSINE has been engaged in the overseas market for 12 years.Up to now,about 3000 sets of equipment have been operating overseas,and the annual failure rate is less than 1%.

    The third,Our products are modular design,If there is a fault,it can be remote fault diagnosis,and then express products’ parts to customer for quick repair.


    About US:

    Kingsine Electric Automation Co., Ltd. has been specializing in Research & Development, production and sales of Electric Testing & Measurement Instruments since 1999 foundation who is also honored as the High-tech enterprise certification and Software enterprise certificate recognized by China authority. With about high development speed every year, Kingsine win the Chinese top manufacturer for electric test equipmentin the domestic relay-tester market.China Guodian Corporation,State Grid Corporation of China,China Southern Power Grid Company Limited and many other national companies use our products.


    (KINGSINE PRODUCTIS EXHIBITION IN DUBAI)
